Wave AP Gen2
The Wave-AP-Gen2 (Wave AP Gen2) is a 60 GHz PtMP access point powered by Wave Technology with 90° sector coverage, 31 client capacity, and dual 2.5 GbE and 10G SFP+ connectivity for wireless ISP and campus network deployments across East Africa. This outdoor 60 GHz PtMP access point delivers:
Perfect for wireless ISPs, campus networks, building-to-building links, high-capacity PtMP backhaul, and any deployment requiring 90° wide-area sector coverage, 5.4 Gbps throughput, 31 client capacity, dual 2.5 GbE and 10G SFP+ WAN ports, and Wave Technology optimisation across East and Central Africa.
DATASHEET
- 60 GHz main radio with 5.4 Gbps maximum total throughput and 90° sector coverage
- 5 GHz WiFi 6 weatherproof backup radio with 800+ Mbps throughput
- (1) 2.5 GbE RJ45 and (1) 10G SFP+ ports
- 31 client capacity supporting Wave Pro (6 km), Wave Long-Range (6 km), Wave Nano (4 km), and Wave Pico (0.9 km) link ranges
- 20 dBi antenna gain at 60 GHz with 90° azimuth and 7° elevation beamwidth
- 13 dBi backup radio antenna at 5 GHz with 95° azimuth and 25° elevation beamwidth with 18 dB cross-pol isolation
- Integrated GPS and Bluetooth
- Wave AI and Wave Technology optimisation
- IPX6 weatherproofing and -40°C to 60°C operating range
- 109.8 N wind loading at 200 km/h and pole mount support for 25.4–60 mm diameter poles
- Passive PoE powered at 24W maximum with included 48V DC 2.5 GbE PoE adapter
Perfect for wireless ISPs, campus networks, building-to-building links, high-capacity PtMP backhaul, and any deployment requiring 90° wide-area sector coverage, 5.4 Gbps throughput, 31 client capacity, dual 2.5 GbE and 10G SFP+ WAN ports, and Wave Technology optimisation across East and Central Africa.
DATASHEET
About the Wave AP Gen2
The Wave-AP-Gen2 (Wave AP Gen2) is a next-generation 60 GHz Point-to-Multipoint access point powered by Wave Technology — delivering 5.4 Gbps throughput through a 90° wide-area sector to serve up to 31 client stations simultaneously across extended ranges up to 6 km. Measuring 158.3 × 286.8 × 100.2 mm (6.2 × 11.3 × 3.9") and weighing 1.5 kg (3.3 lb), the Wave-AP-Gen2 features a UV-stabilised polycarbonate and aluminium alloy enclosure with IPX6 weatherproofing, supporting pole diameters of 25.4–60 mm (1–2.4"). The dual-port configuration — (1) 2.5 GbE RJ45 and (1) 10G SFP+ port — provides flexible copper and fibre uplink connectivity. Powered by a Quad-core ARM® Cortex®-A53 at 1.4 GHz with 512 MB memory. Requires UISP version 2.4.205 and later.
The 60 GHz main radio operates across 57–71 GHz worldwide with channel bandwidths of 2160, 1080, and 540 MHz and 16QAM and QPSK modulation. The 20 dBi vertically-linear polarised antenna with 90° azimuth and 7° elevation beamwidth delivers wide-area sector coverage matching the Wave AP Micro's sector width but with updated Gen2 hardware and improved connectivity options. The 5 GHz WiFi 6 (802.11ax) backup radio with 13 dBi dual-linear polarised antenna, 95° × 25° beamwidth, and 18 dB cross-pol isolation maintains link availability during adverse East African weather conditions. WPA2-PSK (AES) encryption secures all wireless links. Integrated GPS enables GPS synchronisation.
Advanced software features include:
Ideal for wireless ISPs, campus networks, building-to-building links, and high-capacity PtMP backhaul deployments across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring 60 GHz 5.4 Gbps wide 90° sector PtMP access, 31 client capacity, dual 2.5 GbE and 10G SFP+ ports, 5 GHz WiFi 6 backup radio, and UISP-managed Wave Technology at up to 6 km range.
The 60 GHz main radio operates across 57–71 GHz worldwide with channel bandwidths of 2160, 1080, and 540 MHz and 16QAM and QPSK modulation. The 20 dBi vertically-linear polarised antenna with 90° azimuth and 7° elevation beamwidth delivers wide-area sector coverage matching the Wave AP Micro's sector width but with updated Gen2 hardware and improved connectivity options. The 5 GHz WiFi 6 (802.11ax) backup radio with 13 dBi dual-linear polarised antenna, 95° × 25° beamwidth, and 18 dB cross-pol isolation maintains link availability during adverse East African weather conditions. WPA2-PSK (AES) encryption secures all wireless links. Integrated GPS enables GPS synchronisation.
Advanced software features include:
- Wave AI for automated link optimisation
- Wave Technology for multi-gigabit 60 GHz performance
- UISP integration, ping watchdog, NTP client, and SNMP
- Antenna alignment, site survey, speed test, traceroute, cable test, and discovery utilities
- Bridge mode networking
- Wind loading: 109.8 N at 200 km/h (25 lbf at 125 mph)
- Supported voltage range: 44–54V DC / 22–27V DC
- Operating temperature: -40°C to 60°C (-40°F to 140°F)
- Operating humidity: 5–95% non-condensing
- FCC, IC, and CE certified, fully NDAA compliant
Ideal for wireless ISPs, campus networks, building-to-building links, and high-capacity PtMP backhaul deployments across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring 60 GHz 5.4 Gbps wide 90° sector PtMP access, 31 client capacity, dual 2.5 GbE and 10G SFP+ ports, 5 GHz WiFi 6 backup radio, and UISP-managed Wave Technology at up to 6 km range.
