The
RG-RAP1261 is an
ultra-compact wall-plate Wi-Fi 6 access point designed for single-room hospitality and office wireless deployments. This
802.11ax wall-plate AP features
2×2 MU-MIMO on both 2.4 GHz and 5 GHz bands with
backward compatibility to Wi-Fi 5/4 (802.11ac/n/a/b/g).
Integrated 2.4 GHz and 5 GHz antennas: 2 built-in omnidirectional antennas with 3 dBi gain on both bands provide reliable in-room coverage.
Advanced modulation support including OFDM (BPSK, QPSK, 16-QAM, 64-QAM), DSSS (DBPSK, DQPSK, CCK), MIMO-OFDM (BPSK through 1024-QAM), and OFDMA ensures efficient wireless performance.
The
RG-RAP1261 features
2 Gigabit Ethernet ports (10/100/1000BASE-T) enabling connection of wired devices including IP TVs, VoIP phones, desktop computers, or set-top boxes without requiring separate switches.
PoE/PoE+ powered (IEEE 802.3af/at) with maximum 10.2W power consumption enables single-cable installation from PoE switch to wall-plate.
Ultra-compact wall-mount design with 86 mm × 42.4 mm × 86 mm dimensions (3.39 in. × 1.67 in. × 3.39 in.) and
ultra-lightweight ≤0.16 kg (0.35 lbs) provides clean, professional installation.
Junction box mounting option offers flexible deployment.
Operating temperature range of
0°C to 40°C (32°F to 104°F) with
-40°C to +70°C storage temperature and
5-95% humidity tolerance support indoor environments.
Receive sensitivity ranges from -91 dBm (11b @ 1 Mbps) to -49 dBm (11ax @ 160 MHz MCS11) for reliable connectivity.
±2 kV surge protection on Ethernet ports for common mode safeguards equipment.
400,000 hours MTBF ensures long-term reliability.
System status LED and
reset button provide operational control.
Management via Ruijie Cloud platform, Reyee mobile app, or standalone web GUI.
CE, FCC, CB certifications with RoHS compliance and EN 62368-1 safety compliance.
Ideal for
hotel guest rooms and executive suites, residential apartments and serviced accommodations, executive offices and private workspaces, hospital patient rooms, individual consultation offices, and single-room deployments requiring
Wi-Fi 6 performance with integrated 2-port Gigabit switch, PoE power, and ultra-compact wall-plate form factor across East Africa.
✅ IN STOCK
