The
LBE-5AC-Gen2 (airMAX LiteBeam 5AC Gen2) is an
ultra-lightweight 5 GHz PtP bridge with airMAX ac chipset, dedicated management WiFi, and 23 dBi gain for fast-deploy cost-effective point-to-point wireless connectivity across East Africa. This
lightweight 5 GHz PtP bridge with mobile app management delivers:
- 23 dBi antenna gain across 5150–5875 MHz worldwide
- 15+ km link range
- 450+ Mbps throughput
- 25 dBm maximum TX power output
- Dedicated WiFi management radio (2412–2472 MHz worldwide)
- Easy to assemble design
- Passive PoE 2-pair powered at 7W maximum (22–27V DC)
- 24V, 0.3A gigabit PoE adapter included
- (1) GbE RJ45 networking interface
- 200 km/h wind survivability — 275 N wind loading (61.8 lbf at 125 mph)
- 358 × 271.95 × 272.5 mm (14.1 × 10.7 × 10.7") — 800 g without / 980 g with mount
- Pole mount kit included
for building-to-building links, enterprise backhaul, ISP last-mile, campus connectivity, and fast-deploy remote site connections across Kenya, Uganda, and the region.
Perfect for
building-to-building links, enterprise wireless backhaul, ISP last-mile, campus connectivity, remote site connections, and any deployment requiring lightweight, easy-to-assemble 5 GHz PtP bridge performance with mobile app management, 23 dBi gain, and fast deployment across
East and Central Africa.
DATASHEET
